Titan M Series Custom
Custom Electric Forklifts (3,200–96,000 lbs)
TQZ – Multi-Directional Reach Truck
Design: Side-seated, full-forward multi-directional design with three independent steering wheels for exceptional maneuverability in tight spaces.
Comfort: Ergonomic operator compartment with clear visibility and HD camera display for precise and comfortable operation.
Performance: Lithium electric drive with full-proportional load sensing and selectable speed modes for smooth, responsive handling.
Safety: Arc-narrowed chassis, stable steering system, and advanced electric controls for safe operation in ultra-narrow aisles.
Technical Specs
Model | TQZ |
Power type | Battery |
Driving type | Seated |
Load capacity Q(kg) | 2500 |
Load center distance C(mm) | 600 |
Service weight (incl. battery) kg | 5100 |
Fork tilt range: front/rear α/β(°) | 2/4 |
Lift height h3(mm) | 8500 |
Overall length l1(mm) | 2550 |
Overall width b1/b2(mm) | 1770/2770 |
Fork dimensions l/e/s(mm) | 1070x125x45 |
Fork outside spread b5(mm) | 400~840 |
Reach distance l4(mm) | 656 |
Turning radius Wa(mm) | |
Travelling speed, laden/unladen km/h | 8~10 |
Battery voltage/nominal capacity V/Ah | 48/700 |
Battery replacement method | Front pull and hoist |
TFE15D – Double Deep Stand on Reach Truck
Design: Scissor telescopic reach mechanism with compact chassis for maximum storage density and tight aisle operation.
Performance: Full AC maintenance-free drive system delivers efficient power, smooth acceleration, and reliable high-lift handling.
Control: Precision reach and lift control with integrated sensors for optimized speed, stability, and responsive operation.
Safety: Automatic lowering speed control, buffer protection, and advanced monitoring systems ensure safe, confident material handling.
Technical Specs
Model | TFE15D |
Power type | Battery |
Driving type | Stand on |
Load capacity Q(lbs) | 1450 |
Load center distance C(mm) | 600 |
Service weight (incl. battery) lbs | 4340 |
Lift height h3(mm) | 7515 |
Minimum height of fork surface h13(mm) | 2260 |
Overall length(not incl. fork) | 2115 |
Overall width b1/b2(mm) | 1080/1364 |
Fork outside width b5(mm) | 222~702 |
Inner leg width b4(mm) | 1060 |
Driving speed, load/unloaded km/h | 8/10 |
Battery voltage/nominal capacity V/Ah | 48/550 |
Battery replacement method | Side Pull |
TJ 30 – Articulated Forklift
Design: Articulated chassis allows tight turning and efficient operation in narrow aisles while maintaining full reach capability.
Performance: 3,000 kg capacity with lift heights up to 8 metres, delivering strong stability and consistent capacity retention at height.
Control: Finger-tip hydraulic controls, digital directional display, and keypad start provide precise handling and secure operation.
Safety & Efficiency: Tortoise mode, dual horn system, and articulated steering improve safety, reduce aisle width requirements, and increase overall warehouse productivity.
Technical Specs
Model | TJ 30 |
Power type | Battery |
Driving type | Seated |
Load capacity Q(kg) | 3000 |
Load center distance C(mm) | 600 |
Service weight (incl. battery) kg | 8280 |
Fork tilt range: front/rear α/β(°) | 1/3 |
Lift height h3(mm) | 4600~8000 |
Overall length l1(mm) | 3830 |
Overall width b1/b2(mm) | 980/1600 |
Fork dimensions l/e/s(mm) | 45x125x1100 |
Fork outside spread b5(mm) | 380~890 |
Side Shift Distance | +- 100 |
Turning radius Wa(mm) | 2200 |
Travelling speed, laden/unladen km/h | 12~13 |
Battery voltage/nominal capacity V/Ah | 80/500 |
Battery Weight(kg) | 1380 |
Model | Type | Load Capacity | Lift Height | Ideal Applications |
TQZ | Multi-Directional Reach Truck | 2,500 kg | Up to 8,500 mm | High-bay warehousing, narrow aisles |
TFE15D | Double Deep Stand on Reach Truck | 1,450 kg | Up to 7,515 mm | General warehousing, pallet stacking |
TJ 30 | Articulated Forklift | 3,000 kg | Up to 8,000 mm | Long material handling, indoor/outdoor |
TFE20S – Single Scissor Reach Truck
Design: Compact, streamlined design with stand-on operation and four-point support.
Comfort: Ergonomic dashboard, integrated handle, and widened armrest for operator comfort.
Performance: High-load mast with minimal sway, ensuring stability at high lifts.
Safety: Operator presence detection system (OPS) and LED lighting for enhanced safety.
Technical Specs
Model | TFE20S |
Forward mechanism type | Single scissor |
Power type | Battery |
Driving type | Stand on |
Load capacity Q(kg) | 2000 |
Load center distance C(mm) | 600 |
Service weight (incl. battery) kg |
|
Fork tilt range: front/rear α/β(°) | 3/4 |
Lift height h3(mm) |
|
Overall length l1(mm) |
|
Overall width b1/b2(mm) | 1080/1364 |
Fork dimensions l/e/s(mm) | 1070/100/40 |
Fork outside spread b5(mm) | 222-702 |
Reach distance l4(mm) | 600 |
Turning radius Wa(mm) |
|
Travelling speed, laden/unladen km/h | 8/10 |
Battery voltage/nominal capacity V/Ah | 48/550 |
Battery replacement method | Side pull |
TWPS – Walkie Wide-Leg Pallet Stacker
Design: Walkie-type with wide-leg support for increased stability.
Performance: Efficient handling of pallets with a lift height up to 5,000 mm.
Safety: Emergency reverse button (belly button) to prevent operator injury.
Battery: Side pull battery design for easy replacement and maintenance.
Technical Specs
Model | TWPS |
Power type | Battery |
Driving type | Walkie |
Load capacity Q(lbs) | 4410 |
Load center distance C(in) | 23.6 |
Service weight (incl. battery) lbs | 3260 |
Lift height h3(in) | 196.9 |
Minimum height of fork surface h13(in) | 2.5 |
Overall length l1(in) | 79.5 |
Overall width b1/b2(in) | 33.5/58.3 |
Fork outside width b5(in) | 7.9-31 |
Inner leg width b4(in) | 50 |
Outer leg width b6(in) | 58.3 |
Turning radius Wa(in) | 59.8 |
Driving speed, load/unloaded mph | 4 |
Driving speed, load/unloaded, backward mph | 4 |
Maximum climbing ability, load/unloaded % | 5/10 |
TMD – Multi-Directional Forklift
Design: Seated operation with 360° multi-directional driving capability.
Performance: Handles loads up to 5,000 kg with lift heights up to 7,000 mm.
Safety: HD camera, OPS system, and LED lighting enhance operational safety.
Battery: 80V/500Ah lithium battery ensures zero maintenance and quick charging.
Technical Specs
Model | TMD |
Power type | Battery |
Driving type | Seated |
Load capacity Q(kg) | 5000 |
Load center distance C(mm) | 600 |
Service weight (incl. battery) kg | 7750 |
Fork tilt range: front/rear α/β(°) | 2/4 |
Lift height h3(mm) | 6000 |
Overall length l1(mm) | 2300 |
Overall width b1/b2(mm) | 2710/2960 |
Fork dimensions l/e/s(mm) | 1200/150/50 |
Fork outside spread b5(mm) | 560-2900 |
Reach distance l4(mm) | 1300 |
Travelling speed, laden/unladen km/h | 7.0-8.0 |
Battery voltage/nominal capacity V/Ah | 80/500 |
Model | Type | Load Capacity | Lift Height | Ideal Applications |
TFE20S | Single Scissor Reach Truck | 2,000 kg | Up to 8,000 mm | High-bay warehousing, narrow aisles |
TWPS | Walkie Wide-Leg Pallet Stacker | 2,000 kg | Up to 5,000 mm | General warehousing, pallet stacking |
TMD | Multi-Directional Forklift | 5,000 kg | Up to 7,000 mm | Long material handling, indoor/outdoor |
